的主要用途与简单：/Purpose and introduction

服用液洗烘灌轧三级互通线由落地超声清洁工作心动图波洗瓶机、隧道口式内重复 重复无菌处理烘干阶段箱、服用液灌装设备线轧盖机等包含，适于于 5-30ml 等不一样规 格服用液瓶的研发。可顺利完成对放射性药品研发中安瓿瓶淋水、超声清洁工作心动图波清洁工作、冲水、充 气、烘干阶段无菌处理、散热、灌装设备线、轧盖等工序步聚的三级互通开机运行。Oral liquid washing drying filling and rolling line by the vertical ultrasonic bottle-washing machine, tunnel sterilization oven hot wind cycle, oral liquid filling and other components of the rolling machine, suitable for 5-30 ml different gauge, etc Oral liquid bottle production. Can be done for ampoule bottle pour water in drug production, ultrasonic cleaning, flushing, filling gas, drying sterilization, cooling, filling and rolling cover joint operation of the process steps.

优缺点:/characteristic

◆洗瓶机主要包括机制手夹瓶，采用四种年纪的瓶盖；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of the bottle;◆洗瓶选取水蒸汽喷针往复运动监测添加的方式，擦洗特效好，开源节流发热能源。并包括针架防跳动传动装置，增强喷针添加塑料瓶的为准度，少断针的现象会发生；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶全部水雾蒸汽管道、喷针仍然独力单独，防止了交差被污染的，符合国家GMP规范起来规定要求；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶螺旋轴前改加响应块，有呵护螺旋轴，可以减少碎瓶功用Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottles◆洗瓶机出瓶应用布局进口商发送到带，联接拨块推送服用液，程序运行相对稳定不靠谱In pieces out of the bottle inside the whole import synchronous belt, the connection piece of conveying liquid, stable and reliable running◆真空烘箱分为红外线热处理加散铜管，不锈钢304热处理加散铜管双重热处理煮沸气温饱满性好；Oven using infrared heating tube, stainless steel heating tube double heating temperature uniformity is good;◆灌装生产线轧盖机可以配瓷质泵、不锈钢材料泵；In pieces filling rolling machine optional ceramic pump, stainless steel pump;◆装灌无瓶止灌，无瓶不轧盖功能键。Pieces filling without bottle filling, no bottle no rolling function.◆整线选取PLC总的控住、直流变频空调器、手触屏的控住技能，工作维持牢靠。手触屏可凸显各手机单机的工作睡眠的情况，各的控住点的通水压力、气压表、风速、湿度等凸显，各转换开关睡眠的情况和机械电脑故障问题凸显，机械电脑故障问题自我价值的诊断和机械电脑故障问题介绍及检测工艺。使一整个加工阶段达到重新化的控住，联线具有着三机自我控制稳定平衡裝置，可以保障加工营养均衡牢靠。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. The whole production process to achieve automatic control, on-line has the compressors control balancing device, ensure production is balanced.会按照老客户的必须，还可供配搭：According to the needs of customers, but also available for selection:◆simens、德力西、三菱数控设计、台达等项目掌握设计；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气压强、水的温度及彩超波屈服强度、玦尘塑料颗粒、风速等级在线上在线检测、报警功能、记录查询、印刷装置。Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system.◆ORABS、CRABS、无菌检测底部隔离器设计。Mixer ORABS, CRABS, aseptic isolator system.

高技术性能：technical parameters

用于技术参数Cutting   dimension(ml)	5-25
生产能力production capacity(pcs/min)	350
灌装生产线高精准度Filling accuracy(%)	≤ ± 2.5
罐装头数Fillingheads	16
轧盖头数Number of rolling   curtain	单刀20头
轧盖合理率Rolling cover   percent of pass(%)	≥ 99
总重量total weight(kg)	7500
外形尺寸boundary dimension(mm)	9920 × 2003 × 2150
